Transition "Mystery" Color ABS
Our transition color ABS filament is the same high quality ABS filament that our customers trust but in "mystery colors." These varying colors are the result of our changeovers from one of our standard color to another during production of our filament and cannot be reproduced. While supplies last. Items are not returnable or refundable due to color.
Note: These are not a rainbow filament.  The color change in each spool will vary and be very gradual.
*This product is limited to availability as we make changeovers. If you cannot add it you your cart, we are sorry, but we are out of stock.

Technical Printing Guide - COEX ABS
1. Material Notes

Keep filament dry - store properly and dry before use
If needed, dry at 75°C for 3 hours or more
Enclosure is nessecary
Use Z-offset slightly higher than PLA (+0.05mm)
Enable "Avoid crossing perimeters" to reduce stringing
Consider using the "Wipe while retract" option
Enable "Slow down for small perimeters."
Print outer walls slower for better quality
Use a minimum layer time of 30 seconds for small parts

Consider using "Extra Prime Amount" after retraction

2. Temperature Settings
Bed Temperature: 80-100°C

Wash the bed often for good adhesion - Use dish soap and rinse thoroughly to remove oils
Use bed adhesion products if necessary (gluestick, WELD3D)
Use brim for tall or large prints
Keep the ambient temperature stable

Extruder Temperature: 245-265°C
3. Basic Parameters



Nozzle
Layer Height
Line Width
Volumetric Speed
Temperature


0.4mm
0.2mm
0.42mm
14.0 mm³/s
250°C


0.6mm
0.3mm
0.62mm
31.5 mm³/s
255°C


0.8mm
0.4mm
0.82mm
56.0 mm³/s
260°C


 1.0mm
0.5mm
1.02mm
87.5 mm³/s
265°C






4. Speed Settings
0.4mm Nozzle (Volumetric Speed: 14.0 mm³/s)



 Line Type
Percentage
Speed


External Perimeter
50%
83.33 mm/s


Internal Perimeters
75%
125.00 mm/s


Infill
100%
166.67 mm/s


Top/Bottom
60%
100.00 mm/s


First Layer
30%
50.00 mm/s




0.6mm Nozzle (Volumetric Speed: 31.5 mm³/s)



 Line Type

Percentage
Speed


External Perimeter
50%
84.68 mm/s


Internal Perimeters
75%
127.02 mm/s


Infill
100%
169.35 mm/s


Top/Bottom
60%
101.61 mm/s


First Layer
30%
50.81 mm/s






0.8mm Nozzle (Volumetric Speed: 56.0 mm³/s)



 Line Type
Percentage
Speed


External Perimeter
50%
85.37 mm/s


Internal Perimeters
75%
128.05 mm/s


Infill
100%
170.73 mm/s


Top/Bottom
60%
102.44 mm/s


First Layer
30%
51.22 mm/s




1.0mm Nozzle (Volumetric Speed: 87.5 mm³/s)



 Line Type
Percentage
Speed


External Perimeter
50%
85.78 mm/s


Internal Perimeters
75%
128.68 mm/s


Infill
100%
171.57 mm/s


Top/Bottom
60%
102.94 mm/s


First Layer
30%
51.47 mm/s




4. Retraction Settings
IMPORTANT: Set travel speed to the maximum your machine allows (200-500mm/s). Faster movements reduce filament oozing time, minimizing stringing.



Nozzle
Distance
Speed
Z-Hop


0.4mm
1.0-1.5mm
40mm/s
0.2mm


0.6mm
1.0-1.5mm
40mm/s
0.2mm


0.8mm
1.0-1.5mm
40mm/s
0.2mm


1.0mm
1.0-1.5mm
40mm/s
0.2mm




6. Cooling Settings
Cooling Configuration:



First Layer: 0% (fan off)
General Printing: 100% base fan speed
Bridges and Overhangs: 100% fan speed
Layers < 15 seconds: 100% fan speed



7. Troubleshooting Guide



 Problem
Solution


Irregular extrusion

1. Dry the filament
2. Check the extruder
3. Reduce speed



Poor adhesion

1. Dry the filament
2. Use adhesive
3. Adjust the first layer



Stringing

1. Dry the filament
2. Adjust retraction
3. Increase travel speed
4. Check temperature





PLEASE NOTE: These printing parameters are initial recommendations based on our experience. They may need adjustment depending on your specific 3D printer, environmental conditions, and the geometry of the part you are printing. Use these settings as a starting point and fine-tune them according to your specific needs.

.docs-container {
margin: 2em 0;
}
.docs-section-wrapper {
margin-bottom: 1.5em;
padding-bottom: 1.5em;
border-bottom: 1px solid #e0e0e0; /* Simple line separator */
}
/* Remove the last separator line for a clean finish */
.docs-container .docs-section-wrapper:last-child {
border-bottom: none;
margin-bottom: 0;
padding-bottom: 0;
}
.docs-accordion summary {
cursor: pointer;
padding: 0.5em 0;
list-style: none;
display: flex;
justify-content: center;
align-items: center;
}
.docs-accordion summary::-webkit-details-marker {
display: none;
}
.docs-title {
text-align: center;
}
.docs-title h3 {
margin: 0;
font-weight: bold;
display: inline;
}
.docs-accordion summary::after {
content: '▼';
font-size: 0.8em;
margin-left: 0.5em;
transition: transform 0.2s;
flex-shrink: 0;
}
.docs-accordion[open] > summary::after {
content: '▲';
}
.docs-content {
padding: 1em 0 0 0;
}
.docs-content-paper {
max-width: 850px;
margin: 1em auto;
padding: 2em;
border: 1px solid #ddd;
box-shadow: 0 0 10px rgba(0,0,0,0.05);
background: white;
}

/* --- NEW: Blue Link Styling --- */
.docs-container a {
color: #005BD3; /* Standard Shopify link blue */
text-decoration: none;
font-weight: bold;
}
.docs-container a:hover {
text-decoration: underline;
}
.docs-main-link, .docs-download-link {
display: block;
text-align: center;
}
.docs-main-link {
margin-bottom: 1.5em;
}
.docs-download-link {
padding-top: 0.75em;
}

/* --- Mobile Responsive Fixes --- */
@media (max-width: 768px) {
.docs-content-paper {
padding: 1em;
overflow-x: auto;
}
.docs-title h3 {
font-size: 1.1em;
}
}






Coex 3D Filament Slicer Profiles






CX01 ABS Technical Data Sheet





.datasheet-table { border-collapse: collapse; width: 100%; margin-bottom: 1em; }
.datasheet-table th, .datasheet-table td { border: 1px solid #cccccc; padding: 8px; text-align: left; }
.datasheet-table th { background-color: #f2f2f2; }
.datasheet-h4 { font-family: sans-serif; }

Technical Data Sheet: CX01 ABS SERIES 3D PRINTING FILAMENT
TDS Rev 2.0
BASE RESIN: CHIMEI General ABS POLYLAC Ultra-High Impact Strength
Physical Properties

PropertyStandardUnitTypical Value
Specific Gravity - DensityASTM D792g/cm³1.03Melt Density @220°C, 10KGASTM D1133g/10 min13UL Flammability Class. @1.5mmUL 94N/A94HB

Mechanical Properties

PropertyStandardUnitTypical Value
Tensile Yield StrengthASTM D638MPa40Tensile ModulusASTM D638MPa2350Tensile ElongationASTM D638%35Flexural StressISO 178MPa58Notched Izod ImpactASTM D256J/m285Shrinkage Rate < 1%ASTM D955mm/mm0.40 - 0.70%

Thermal Properties

PropertyStandardUnitTypical Value
Glass Transition Temperature (Tg)DSC°C105Heat Distortion Temp @ 0.45MPaASTM D648°C85Decomposition TemperatureASTM 3418°C300

SPECIFICATIONS

Filament Size:1.75mm(in)2.85mm(in)
MIN Diameter:1.72mm0.0677 in2.79mm0.1098 inMAX Diameter:1.78mm0.0701 in2.91mm0.1146 inTolerance+/- .03mm+/- 0.0012 in+/- .06mm+/- 0.0024 in

CERTIFICATIONS
ROHS compliant to (2011/65/EU), 2003/11/EC, TCO'07, Blue Angel and SONY Std. (SS-00259)
NSF/ANSI/CAN 61 Drinking Water System Components
UL/C-UL Certified Yellow Card E56070
Printed Specimen Conditions

Printer:Open Source FDM/FFFNozzle:0.4mmLayer Height:0.25mmInfill:100%, +/-45°Extrusion Temp:240°CBed Temp:90°CSpecimen Orientation:XY FlatUnannealed

Disclaimer: The technical data contained on this data sheet is furnished without charge or obligation and accepted at the recipient's sole risk. This data should not be used to establish specifications limits or used alone as the basis of design. The data provided is not intended to substitute any testing that may be required to determine fitness for any specific use.





Download TDS (PDF)











CX01 ABS Safety Data Sheet





.msds-table { border-collapse: collapse; width: 100%; margin-bottom: 1em; }
.msds-table th, .msds-table td { border: 1px solid #cccccc; padding: 8px; text-align: left; vertical-align: top; }
.msds-table th { background-color: #f2f2f2; }
.msds-section { margin-bottom: 1.5em; }
.msds-section h4 { font-family: sans-serif; border-bottom: 1px solid #eee; padding-bottom: 0.3em; }
.msds-subsection { display: flex; flex-wrap: wrap; }
.msds-subsection .label { font-weight: bold; width: 200px; flex-shrink: 0; }
.msds-subsection .data { flex-grow: 1; }

Material Safety Data Sheet: CX01 ABS SERIES 3D PRINTING FILAMENT
MSDS Rev 1.0
BASE RESIN: CHIMEI General ABS POLYLAC Ultra-High Impact Strength


1. Identification of the substance/preparation and of the company
1.1 Trade name:Coex ABS 3D printer filament
1.2 Use of the product:3D printer filament, thermoplastic polymer
1.3 Supplier:Coex660 Corporate WAYPulaski, WI 54162Phone: (920) 757-1055



2. Hazards identification
2.1 Classification:Combustible Dust
2.2 Special advice on hazards:May form combustible dust concentrations in air. While this product may not be a combustible dust as sold, further processing or handling may form combustible dust concentrations in air.



3. Composition / information on ingredients
3.1 Chemical characteristics:

CAS #Hazardous ComponentsConcentration

9003-54-7Styrene Acrylonitrile Copolymer<=95 %
1333-86-4Carbon black<=5.0 %





4. First-aid measures
4.1 On skin contact:In case of contact with molten polymer immediately cool the skin with cold water. Medical aid may be required to remove adhering material and for treatment of burns.
4.2 After inhalation:Remove from exposure and move to fresh air immediately. If not breathing, give artificial respiration. If breathing is difficult, give oxygen. Get medical aid.
4.3 On ingestion:If swallowed, wash out mouth with water provided person is conscious. Call a physician.
4.4 On eyes contact:In case of contact, immediately flush eyes with copious amounts of water for at least (15) minutes.



5. Fire-fighting measures
5.1 Suitable fire extinguishing media:Water spray and foam. Water is the best extinguishing medium.
5.2 Special exposure hazards:Emits toxic fumes under fire conditions. Approved positive pressure demand breathing apparatus (SCBA) and protective clothing should be used for all fires.
5.3 Special protective equipment:Self-contained breathing apparatus
5.4 Remark:Carbon dioxide and carbon monoxide generated when the material burns. Combustible Dust may form during material transfer. Estimated Dust Explosion Class = ST2; Kst estimated (bar.m/s): >200 -



6. Accidental release measures
6.1 Personal precautions:Use suitable protective clothing. Avoid eye contact and inhalation of dusts. Keep ignition sources away.
6.2 Methods for cleaning up:Vacuum or sweep up material and place into a suitable disposal container.



7. Handling and storage
7.1 Handling:Avoid contact with molten polymer. Avoid generation of dust and electrostatic charge.
7.2 Storage:Protect against moisture. Store cool and keep packaging closed when not in use. Avoid sources of ignition.



8. Exposure controls/ personal protection
8.1 Technical safety measures:Use with adequate ventilation. Minimize dust generation and accumulation as combustible dust mixtures may be formed.
8.2 Personal safety equipment:Use adequate safety equipment, e.g. protective clothing, eye protection glasses, heat protection gloves. In case of dust formation wear mask with particle filter.
8.3 Work hygiene:No eating or drinking during working. Avoid contact of hot material with the skin. Avoid breathing dust and vapors.



9. Physical and chemical properties
9.1 Form:Spool
9.2 Color:Various
9.3 Odor:Almost Odorless
9.4 Melting Temperature:250 °C
9.5 Oxidizing properties:Not self-igniting / flammable
9.6 Explosions limits:Class = ST2
9.7 Density:1.27 g/cm³
9.8 Solubility in water:Insoluble



10. Stability and reactivity
10.1 Stability:The product is stable at recommended storage conditions.
10.2 Conditions to be avoided:Stable under recommended conditions of storage and handling.
10.3 Substances to be avoided:No special recommendations.
10.4 Hazardous decomposition products:Processing fumes evolved at recommended processing conditions may include trace levels of low molecular weight hydrocarbon fragments, carbon dioxide, carbon monoxide and Irritating fumes and gases.



11. Toxicological information
11.1 Local irritation:No data available.
11.2 Other remarks:No data available.



12. Ecological information
12.1 Ecological info:This product is not classified as environmentally hazardous. However, this does not exclude the possibility that large or frequent spills can have a harmful or damaging effect on the environment.
12.2 Biological degradation:No data available.
12.3 Bioaccumulation:This product will not readily bioaccumulate due to its insolubility in water.



13. Disposal considerations
13.1 Product:Chemical waste generators must determine whether a discarded chemical is classified as a hazardous waste. US EPA guidelines for the classification determination are listed in (261) CFR Parts (261.3). Additionally, waste generators must consult state and local hazardous waste regulations to ensure complete and accurate classification. RCRA P-Series: None listed. RCRA U-Series: None listed.
13.2 Uncleaned packaging:Packaging material has to be emptied completely and disposed in accordance with the regulations. Packaging can be recycled if not contaminated.



14. Transport information
14.1 Transport regulations:Not classified as hazardous under transport regulations DOT, ICAO/IATA, IMDG/GGVSee, ICAO/IATA



15. Regulatory information
15.1 EPA regulations: This material meets the EPA 'Hazard Categories' defined for SARA Title III Sections 311/312 as indicated:

Acute (immediate) Health Hazard: No
Chronic (delayed) Health Hazard: No
Fire Hazard: Yes
Sudden Release of Pressure Hazard: No
Reactive Hazard: No




16. Other information
This data is based on the current state of our information and experience. This safety data sheet describes our product in terms of safety requirements. Preceding data is not applicable as a warranty of product properties. It is the responsibility of the recipient to observe the existing legal regulations for the use of this product.


Disclaimer: The safety data contained on this data sheet is furnished without charge or obligation and accepted at the recipient's sole risk. This data describes our product in terms of safety requirements. The data provided is not applicable as a warranty of product properties. It is the responsibility of the recipient to observe the existing legal regulations for the use of this product.





Download SDS (PDF)
